Yanmar

Compact Wheel Loader V4-7

Interested?
787.785.9777

Description Features Specifications

Description

Smooth uneven terrain

Rear axle oscillation allows you to travel over uneven terrain without losing traction or excess material from your bucket. Additionally, you’ll enjoy a smoother ride when encountering bumps or ruts, resulting in less operator fatigue throughout the day.

Features

Performance to move more

The four-cylinder Tier 4 Final Yanmar diesel makes quick work of the biggest jobs with a nearly unstoppable 39HP and the added fuel-efficiency of ECO mode.

Fingertip control

Nothing is ever out of reach with the intuitive design of the operator’s station where you’ll find the loader joystick, two-speed selector and the controls for auto and fixed-speed modes.

Safe and comfortable

Keep operators safe with certified ROPS protection. And keep them comfortable no matter the season with optional cab enclosure with heat and air-conditioning.



Comfort from start to finish

A wide entrance makes for easy ingress and egress, and a reclining, full-suspension seat soaks up uneven terrain for comfort that never tires.

Standard auxiliary hydraulics

Power additional accessories with auxiliary hydraulic connections and set the perfect flow with standard adjustable proportional control.

Fixed travel speed

Working smart and safe is the rule of every jobsite and a fixed travel speed mode employs additional safety when working in restricted areas.

Specifications

Engine

Model 4TNV88C-NKAH
Output 39 HP / 2,500 rpm
Displacement 133.6 in³
Type Water-cooled 4-cylinder diesel

Performance

Standard Bucket Capacity 0.65 yd³
Operating Load 2,535 lbs
Lifting Capacity at Low End 7,451 lbs
Tipping Load – Straight 6,070 lbs
Tipping Load, Articulated 5,058 lbs
Breakout Force 6,085 lbs
Dumping Clearance 7’11”
Traveling Speed 11.8 mph
Oscillation Angle ±8 deg
Minimum Turning Radius 12’6″
Min. Ground Clearance 1’3″

PTO

Front Hyd. PTO 3,000 PSI
Front Hyd. PTO 14.8 GPM

Steering

Articulate Angle 40.5 deg
Type Center-Pivot Frame Articulation w/Full Hyd. Power

Transmission

Type Automatic Hydrostatic

Drives

Type 4-Wheel Drive

Brakes

Type Fully Enclosed, Mechanical, Wet, Multiple Disc

Operating Weight

Canopy 7,848 lbs
Cabin 8,422 lbs

Transport Dimensions

L x W x H 14’6″ x 5’7″ x 8’5″

Like this model or can’t find the one you need? Contact us and we’ll get back to you as soon as possible. You can also call us at 787-785-9777.
